Engine: Daytona Anima 190F 4V

A true powerhouse in the pit bike engine lineup.

The renowned Japanese company Daytona, famous for its pit bike tuning kits, has unveiled its latest innovation - a 4-valve engine for pit bikes, boasting a record-breaking displacement of 190 cc.

The updated engine lineup, named Anima, includes engines with the following displacements:

• Anima 150F - 4-valve head, displacement of 150 cc.
• Anima 190F - 4-valve head, displacement of 190 cc.

Engines with a displacement of 150cc are already available for retail, while the senior model is undergoing final testing and is expected in March 2012. Esteemed pit bike manufacturers such as YCF and BBR have already announced the launch of new motorcycles equipped with the Daytona Anima 150F engine.

Technical Specifications of Anima 190F:

• Air-cooled, 4-stroke, 4-valve
• Horizontal layout (fits Honda CRF 50 frame and other pit bikes)
• Displacement: 187.2 cc
• Bore and stroke: 62 mm x 62 mm
• Valve size: 24.5 mm (2 intake) and 21 mm (2 exhaust)
• HYVO 94-link timing chain
• Ceramic cylinder coating
• Six-disc wet clutch
• Gear shift pattern: 1-N-2-3-4
• Primary drive 67/18
  • 1st gear - 34/13
  • 2nd gear - 26/15
  • 3rd gear - 25/21
  • 4th gear - 22/24
• CDI ignition system and AC generator

Estimated cost: $1500

And just listen to how it sounds!
